So..... my experiment with Vellum paper didn't work out so well.... I guess the whole issue with crappy laser prints is possibly the toner cartridge has a crappy drum and I noticed some slight issues with the fuser. Unfortunately my printer doesn't have density adjustments... Oh well, I guess I'll have to figure something else out.

In the meantime, here's some pics to keep you guys entertained until my next post comes along. Markin' up and cuttin' out! Need to smooth everything out once it's all cut and drilled.


Coming Soon: Kibble's L'Ectroshop (parts and stuff FS)

Snow_Cat
Posts: 463
Joined: Fri Aug 13, 2010 12:40 pm
Steam ID: Snow_Cat
Location: Here
Contact:

Re: t64 Resurrection

Post by Snow_Cat » Wed Apr 13, 2011 11:56 am

Have you tried cleaning off old transparency sheets for transfer printing?

Tangent- How to clean a transparancy sheet.
Spoiler:
Most of the chemically-manufactured toners are soluable with alcohol; as are most 'permant' inks and etch resist cladding.
  1. Put a used transparancy sheet toner side up on top of a flat stain resistant surface.
  2. Spray with rubbing alcohol (or better yet hand sanatizer).
  3. lay a used second sheet toner side down ontop of the first sheet to spread the solvent around.
  4. Go do something else, or push the toner around between the two sheets. Time required varies by brand of toner and transparancy.
  5. Separate the two sheets and wipe with paper towel.
  6. May be necessary to spray and wipe again to remove residue.

User avatar
Triton
Moderator
Posts: 7396
Joined: Mon May 24, 2004 12:33 pm
360 GamerTag: triton199
Steam ID: triton199
Location: Iowa
Contact:

Re: t64 Resurrection

Post by Triton » Wed Apr 13, 2011 12:51 pm

Snow_Cat wrote:Have you tried cleaning off old transparency sheets for transfer printing?

Tangent- How to clean a transparancy sheet.
Spoiler:
Most of the chemically-manufactured toners are soluable with alcohol; as are most 'permant' inks and etch resist cladding.
  1. Put a used transparancy sheet toner side up on top of a flat stain resistant surface.
  2. Spray with rubbing alcohol (or better yet hand sanatizer).
  3. lay a used second sheet toner side down ontop of the first sheet to spread the solvent around.
  4. Go do something else, or push the toner around between the two sheets. Time required varies by brand of toner and transparancy.
  5. Separate the two sheets and wipe with paper towel.
  6. May be necessary to spray and wipe again to remove residue.
he is already using transparencies for photo-resist etching, i wonder if photo paper would work for toner transfer to things other than PCBs :lol:

Snow_Cat
Posts: 463
Joined: Fri Aug 13, 2010 12:40 pm
Steam ID: Snow_Cat
Location: Here
Contact:

Re: t64 Resurrection

Post by Snow_Cat » Wed Apr 13, 2011 1:24 pm

I know that it definitly works for involuntary transfer to library tables. :facepalm:

User avatar
kibble
Posts: 439
Joined: Wed Jul 29, 2009 10:41 am

Re: t64 Resurrection

Post by kibble » Wed Apr 13, 2011 4:08 pm

That's good info, Snow Cat, unfortunately I usually cut up the transparencies so that I can position them better and because sometimes I print more than one design per sheet. I guess if I did one design and not cut them up I could try that out. I also have a practically brand new laser printer aside that was working well and has toner density adjustment but one day refused to boot up anymore.... I don't know what's wrong with it and I messed with it for a bit, but maybe I'll have to go back and try to get it to work.
Coming Soon: Kibble's L'Ectroshop (parts and stuff FS)

User avatar
kibble
Posts: 439
Joined: Wed Jul 29, 2009 10:41 am

Re: t64 Resurrection

Post by kibble » Thu Apr 14, 2011 12:15 am

Mo' pitchurs! I cut out the rectangle for the LCD so that the LCD fits inside of it and it's flush with the front surface, but it's gonna have a bezel around it to keep it looking neat. Making the LCD fit inside will save some space on the inside of the case for the rest of the electronics. The bezel's not gonna look like in the pic with the strips of wood laying on top of each other, that's just more of a mock up shot. I'm also going to rout out rectangles for the speakers so that they actually sit inside the wood, not on the surface, but not all the way through.





Coming Soon: Kibble's L'Ectroshop (parts and stuff FS)

Snow_Cat
Posts: 463
Joined: Fri Aug 13, 2010 12:40 pm
Steam ID: Snow_Cat
Location: Here
Contact:

Re: t64 Resurrection

Post by Snow_Cat » Thu Apr 14, 2011 1:12 pm

^ ^ ^ ^

User avatar
seanmacdonn
Posts: 58
Joined: Sun May 24, 2009 1:37 pm
Location: H20villle

Re: t64 Resurrection

Post by seanmacdonn » Fri Apr 22, 2011 3:15 am

I like whats going on, and sorry about the bump, but I want to see progress. Also I bought the same screen, but I'm getting a few lines on the side, unmodded, did yours have that?
