UPDATED! 7" SCREEN WITH BUILT IN RECHARGEABLE BATTERIES MOD

Post by andrewdorsey » Thu Apr 30, 2009 1:49 pm

UPDATED: NOW WITH HI RES PICS!!!! :D :mrgreen: :mrgreen: :mrgreen: :D

YOUTUBE VIDEO COMMING TOMORROW!!! :D


Well the title almost says it all, here is what the full name is:
NEW 7" PORTABLE SCREEN WITH BUILT IN RECHARGEABLE BATTERIES MODDED BY ME!!! :D
Anyways...

HERE IT IS!!!
PICS

the power button and the headphone jacks. :D
It's actually a madcatz universal screen. :lol:
the universal av jacks :D
all it takes are the three av plug in things :D


Now for the guts :P
the screen and motherboard
the other boards, rechargeable batteries, etc. :D
MIGHTY PUTTY! :D
All of the guts!
It is weird because the screen says it takes 12 volts, but the rechargeable batteries I am usuing are only 7.2 volts???
Anyway...
IT WORKS!!! :mrgreen:
YAY!!! Something that I modded finally works. :roll:

It has a battery indicator gauge to check how much battery life is left.
Im not the best with the dremel :lol:

Also, when you plug the screen in to charge, if the battery is red, that means that the batteries are charging, if the light is green, that means it is fully charged. :D


PICS OF IT WORKING

Wii!!!
PAPER MARIO!!!
ZELDA!!!
The camera doesn't capture the full quality of the screen, it's a better in person.
This picture of zelda above shows that the screen is completely portable exept for the three red, white, and yellow cords hanging at the bottom. :D
Luigi's Mansion!
Luigi's Mansion didn't come out so well. :?

I don't know if I made this clear or not, but this screen is completely portable, it has batteries built in it.

I had a lot of fun with this project and it only took me like 2 hours to make and it was soooo worth it.
The batteries last about 4 and a half to 5 hours! :D :!: :!: :!:
This project also only cost me 30 bucks to make!
Screen: $20
Batteries: $10

The batteries came with the fuel gauge.

THAT IS ALL FOR NOW!!!

IWILL POST A VIDEO SOON!!!

THANK YOU ALL AND GOOD NIGHT!!! Just kidding.

MODDED BY ADMODDER
Last edited by andrewdorsey on Thu Apr 30, 2009 11:42 pm, edited 2 times in total.
